HIKVISION DVR MINI 04CH HDD 8MP H.265 DS-7104HUHI-K1

U$ 62,30

Em estoque

Código do Produto: 6682

Falar com Atendimento

Nossa equipe está pronta para ajudar você!

Produtos Relacionados

HIKVISION DVR 04CH 4K 1HDD 8MP H.265 PRO+ DS-7204HTHI-K1

U$ 116,00

Ver Detalhes

DS-7104HUHI-K1

Mini DVR 4 canais 5 MP 1U H.265

*NÃO ACOMPANHA HD*

O gravador digital DS-7104HUHI-K1 com AHD (Analog High Definition), HD-CVI (High Definition Composite Video Interface), HD-TVI (High Definition Transport Video Interface), TCP / IP e interface CVBS é um profissional dispositivo aplicável em sistemas de vigilância.

Características Principais

4 canais e 1 mini DVR HDD
Eficiente tecnologia de compressão H.265 pro +
Capacidade de codificação de até 8 MP lite a 15 fps, 5 MP a 12 fps
5 sinais de entrada adaptáveis (HDTVI / AHD / CVI / CVBS / IP)
Até 8 câmeras de rede podem ser conectadas.

Especificações

Recording
Video compression	H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Encoding resolution	8 MP/5 MP/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF
Frame rate	Main stream: ,8MP@8fps/5MP@12fps/4 MP@15fps/3 MP@18fps,1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N),Sub-stream: ,WD1/4CIF/CIF@25fps (P)/30fps (N)
Video bit rate	32 Kbps to 10 Mbps
Dual stream	Support
Stream type	Video, Video & Audio
Audio compression	G.711u
Audio bit rate	64 Kbps
Video and Audio
IP video input	4-ch (up to 8-ch) Up to 8 MP resolution Support H.265+/H.265/H.264+/H.264 IP cameras
Analog video input	4-ch BNC interface (1.0 Vp-p, 75 ), supporting coaxitron connection
AHD input	5 MP, 4 MP, 1080p25, 1080p30, 720p25, 720p30
HDCVI input	4 MP, 1080p25, 1080p30, 720p25, 720p30
CVBS input	PAL/NTSC
Audio input	1-ch, RCA (2.0 Vp-p, 1 KΩ)
Audio output	1-ch, RCA (Linear, 1 KΩ)
Two-way audio	1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
Synchronous playback	4-ch
HDTVI input	8 MP, 5 MP, 4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25
VGA/HDMI output	1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Network
Remote connections	32
Network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
Network interface	1, RJ45 10M/100M self-adaptive Ethernet interface
Network bandwidth	32Mbps
Auxiliary interface
SATA	1 SATA interface
Capacity	Up to 6 TB capacity for each disk
Alarm in/out	N/A
USB interface	2 × USB 2.0
General
Power supply	12 VDC
Consumption (without HDD)	≤ 15 W
Working temperature	-10 °C to +55 °C (+14 °F to +131 °F)
Working humidity	10% to 90%
Dimensions (W × D × H)	200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inch)
Weights (without HDD)	≤ 1.16 kg (2.6 lb)
